Swift Fox Blog

Important Caveat

This blog is no longer maintained, and the posts in it are now quite old and out of date. Some of this advice still applies today, but the technical considerations are likely no longer relevant.


Aug 2014

Building Robust Connections Between Tower Sites

Tower EngineerFor any WISP, having a robust, fast and high capacity distribution infrastructure between sites is one of the key factors in getting clients the full speeds they expect with predictable latency and reliability.

Many WISPs start by building a multi-point access point on their first tower, and then install a number of clients on that access point. This is a typical and ideal configuration.

Often at some point later, there is a need to install another AP at one of those client’s locations to act as a repeater to additional clients.  Using clients as repeaters can be a good, low cost way to expand coverage and reach additional clients.  There are legal and business considerations with this, but for this article I will focus on the technical considerations.

Many WISPs will simply connect another access point at the client location, using the existing connection as the feed for that AP.  In some cases, simply enabling AP-Repeater mode can also look like a quick and inexpensive way to get service to more subscribers.  These two techniques have some significant challenges and are not suited to professional grade services that will then be resold.  These features were included by manufacturers for hobbyists to use as experimental or home-use features only.

What’s wrong with AP-Repeater mode?

Every time an AP-Repeater is used, speed and capacity for all the customers on those access points are cut in half.  Some might say “No big deal, I only have a few users out there, I can afford to reduce speeds”, but the issue is much larger than that.  Here’s how AP-Repeater mode works:

AP#1 is where the Internet feed is supplied, it has 20 subscribers on it, one of them is a

READ MORE...

Author: Scott Armstrong

Jun 2014

WISP Backup Power Solution

Provide reliable monitored multi-day backup power at a tower site for under $500

Power OutageProviding multi-day backup power at all transmitters reduces service calls and improves network reliability significantly.  On many WISP networks, power disruption is the leading cause of client outages.

Most off-the-shelf retail UPS units (eg. APC1100) have very limited run time for their size.  They are designed to provide computers with high wattage, short term power while they are shut down during a power outage.  What a wireless site needs is low wattage, but exceptionally long run times.  In order to obtain monitored long-runtime UPS from vendors like APC, one would have to invest in enterprise UPS products which are typically thousands of dollars and take up significant amounts of space, and will intentionally shut down when operated below freezing.  They are also designed for high wattage applications which raises the cost and space requirements significantly.  Typical tower sites have exceptionally low power draw, but require long run times.  Computer UPS units are simply not designed for this application.

If there is a power failure at a remote location on a Friday night at 10PM it is of great business utility and savings to fix the issue on the following Monday, during business hours.  Often by then, the cause of the outage has been resolved by the power utility or landlord and no site visit with a generator is required.  Also, if there are widespread power outages due to acts of nature, it is not uncommon to have several sites lose power and road access closed by emergency services or impassable roads.  If six sites all lost power, most WISPs do not have enough generator

READ MORE...

Author: Scott Armstrong

May 2014

The Importance of Last Mile Network Monitoring

Providing a consistent Internet Service is a complex challenge. A strong signal and an association between the AP and the client radio is no guarantee of quality service, nor an indicator of the client’s actual online experience.

Many factors can cause either intermittent connection drops or degraded service: multi-path, network congestion, bad equipment, ice build-up, overloaded back hauls and many other unpredictable factors.

As a WISP, if you have a way of knowing the true quality of every client’s connection at all times, you can have a significant impact on your ability to provide consistent service to everyone.

For example, using Swift Fox software you can plot the quality of every client on an access point and see trends and patterns. Is weather having an impact? Is the entire sector having issues at primetime or is it just two specific clients?

Are there patterns in power failures in the service area? Is noise at play? These are all questions that can be answered quickly and easily when there is a complete view of the true status of every single connection 24/7/365.

The traditional way to manage these challenges was to monitor the backhauls and access point for association, signal level and CCQ. Unfortunately this doesn’t provide a complete picture. If the client appears in the association list on the AP, that only indicates that a packet was seen from the device recently.

CCQ is a very unreliable statistic as lightly loaded connections lack the sample size needed to give accurate calculations. Some network monitoring suites send SNMP requests or basic pings to the device every 5 or 10 minutes. This can catch major issues with a client’s connection, but int

READ MORE...

Author: Scott Armstrong

Mar 2014

Starting a WISP Step 2 – Wholesale Internet Access: How it works, How to get it.

WISP Wholesale Internet Access

Internet Gateway:  Finding Fiber

You’ve found your market, they want broadband, and you’ve identified some good tower locations to get service to their homes.   Now you need to secure a high volume of quality broadband Internet to your towers – but how do you do that?

The first step is finding the closest fiber “point of presence” (POP).   This is a location where you can “co-locate” (ie. place your equipment) that has access to a nationwide fiber backbone.   One important caveat – you need real dedicated fiber here. Verizon FIOS or Comcast Xfinity are both delivered over a fiber optic cable, but they aren’t dedicated. They are built on a shared technology called GPON.  For more on this, as well as an explanation of why cable modems, DSL, and “business Internet” won’t work for gateway – see our article on Non-Dedicated Gateway.

The best place to obtain fiber is a data center, as they will usually have several providers to choose from so you can get a great rate.  However, if you’re in the middle of nowhere (the best place to be a WISP!), you probably don’t have access to one nearby.   The next best place to check is large hotels (see if management can tell you where they get service), or large office towers.  If you don’t have any of these options then you’ll have to build wireless “backhauls” to get it out to you.

Swift Fox has a big list of locations and pricing for various fiber providers throughout most of the US and Canada, feel free to contact us and we can help find the options closest to you.

Knowing the Lingo:  What to ask for

When you’re shopping around for wholesale Internet, you have to be v

READ MORE...

Author: Matt Beaton

Feb 2014

WISP Pitfalls: Cable Modems as Gateway

I found cheap “Business Internet” in my town!  Will that work for my WISP?

Your local cable or phone company might offer “Business Internet” packages over DSL/Cable/GPON, and they may even provide some rather large ones, say 100mbit down and 10mbit up.   It’s cheap and available in your area, so why not use that for your main gateway?

Technically you could if these were dedicated 100mbit as they would be a great Internet gateway to start out with. Unfortunately, these connections are not dedicated, they are “oversubscribed”.  Oversubscription is part of the key to how broadband works, and how you can get huge amounts of throughput for cheap as a residential or small business consumer.  Providers will never say it is oversubscribed though, and dedicated is often bandied around by telcos as a marketing term when it is not really dedicated at all.

What you really need is a product called “unmetered dedicated ethernet with 95th percentile billing”, that is normally sold by the large business division of an ISP, or by a company that sells exclusively to other ISPs.   See our article on Wholesale Internet Access for more on how to find a provider like this.

Oversubscription Ratios:  Why Dedicated is the Only Option

Broadband works on the same principle as the sewer and water lines in a city.  If everyone flushed their toilet on a street at the same time, it would overload the system!  When utilities are built, the assumption is that only some people will be using them at any given time, so they oversubscribe the system.  Broadband works the same way.   As an ISP, you might buy 50mbit of gateway, and then sell 200 x 5mbit residential connections on

READ MORE...

Author: Matt Beaton
